External recording workflows depend on the camera’s output signal, the recorder model, supported codec, firmware and post-production software. ProRes RAW, Blackmagic RAW and standard ProRes are distinct formats. A recorder that supports one does not necessarily support the others. This article explains how to verify a camera-recorder combination before a production rather than assuming that Blackmagic Design and Atomos devices share the same RAW recording path.
For a related comparison of modern image and video delivery formats, see our guide to AV1, ProRes RAW and JPEG XL.
Understand the format distinction
Apple ProRes RAW is a RAW video recording format supported by selected camera and recorder combinations. Blackmagic RAW is a separate format developed by Blackmagic Design. Standard Apple ProRes 422 variants are also distinct from ProRes RAW. File extensions or a product’s use of the word “RAW” should not be treated as evidence of codec compatibility.
Blackmagic Video Assist recording formats
Blackmagic Design’s published Video Assist specifications list Blackmagic RAW recording on supported 12G-SDI HDR models and standard ProRes and DNx recording options. The listed Video Assist codec set does not include Apple ProRes RAW. Check the exact Video Assist model and supported camera output in the Blackmagic Video Assist technical specifications.
For a broader explanation of image-format selection and preservation of source masters, see AVIF, JPEG XL and WebP.
Atomos ProRes RAW workflows
Atomos documents ProRes RAW recording on selected monitor-recorders and provides a camera compatibility list. Its documentation states that a usable recording requires a clean HDMI or SDI feed, and that ProRes RAW availability is limited to supported camera and recorder combinations. Check the exact recorder, camera, firmware, input connection, resolution and frame rate in the Atomos camera compatibility list and Atomos ProRes RAW overview.
For the storage performance bottlenecks that affect high-bitrate media ingest, see NVMe storage in AI editing workflows.
Build a compatibility matrix before purchase
| Field | Required verification |
|---|---|
| Camera | Exact model, firmware and clean output capability |
| Recorder | Exact model, firmware and codec licence or activation |
| Connection | HDMI or SDI, connector type, cable length and signal format |
| Recording mode | Resolution, frame rate, bit depth, chroma and RAW format |
| Metadata | Timecode, audio, camera metadata and file naming behaviour |
| Post-production | Supported NLE version, camera-specific plug-in and grading controls |
Validate the full signal path
- Confirm the exact camera and recorder combination in the manufacturers’ current compatibility documentation.
- Set the required output format on the camera and confirm that the recorder recognises the same signal.
- Record a test slate with timecode and audio, then inspect the files in the intended NLE.
- Check frame rate, duration, timecode continuity, audio sync, metadata and any dropped or repeated frames.
- Repeat the test after firmware, cable, output-mode or post-production software changes.
Conclusion
Do not treat ProRes RAW and Blackmagic RAW as interchangeable, and do not assume that a Blackmagic recorder supports Apple ProRes RAW. Verify the exact camera, recorder, signal, firmware and software combination before a shoot. A tested compatibility matrix is more useful than a broad brand-level comparison.
